Tesnit Compressed Gasket Materials - BAGL 3000


bagl-3000

Environment friendly gasket material with excellent torque retention and thermal resistance.


BAGL 3000 is a supreme fiber gasket material produced from a combination of aramide and glass fibers, specially selected fillers and elastomeric binders. With a well-considered selection of all ingredients the material is free of harmful nitrosoamines (certified by MRPRA) and fibers which are hazardous to human health. Additionally, when it is applied at high temperatures, no significant emission of hazardous degradation products has been detected. Its carefully balanced composition provides exceptional thermal stability and torque retention when applied in flanged joints.BAGL 3000 is in compliance with DIN 28091-2 and BS 7531 Grade X requirements.



Basis
Composition Glass fibres, NBR
DIN 28091-2 FA-G1-0
Colour Greenish blue / Green
Approvals applied for BAM, DIN-DVGW (DIN 3535/6), FIRE SAFE - API 607, HTB (DVGW VP 401), TA-LUFT (VDI 2440), TARC/MRPRA, WRAS/WQc

Properties and application



The exclusive properties of BAGL 3000, particularly its superior torque retention, enable its superior performance in high-temperature applications and when high internal pressure is applied. Additionally, superior thermal stability ensures low maintenance costs and high flange connection safety. Special surface treatment on BAGL 3000 facilitates dismantling after use. These unique properties make BAGL 3000 a reliable choice for use in compressors and pumps. BAGL 3000 is also suitable for sealing thermal oils, fuels, Freons and gases, and for general application in pipelines, steam supply, radiators, boilers and many different flanged joints.



Surface Treatment



The standard version has a non-stick top and bottom layer. Additional surface treatment is generally unnecessary. Special treatment with graphite, silicone or PTFE on one or both sides is available on request.
